将Network Edge设备连接到其他服务提供商
使用 Fabric API 从您的网络边缘设备建立与云服务提供商的直接 2 层连接。
Fabric API 先决条件
-
身份验证 - 提交您的 OAuth2 用户凭据、客户端 ID 和客户端密钥 身份验证。请参阅API身份验证以获取有关如何调用OAuth API来验证和认证您的凭据的说明。
-
确定您的 A 端信息。使用 获取虚拟设备 或 获取虚拟设备 {uuid} 获取您的网络边缘设备信息。您可以选择设备上任何可用的接口进行连接。但是，如果您未指定接口，Equinix 将自动选择一个。
-
选择 Z 侧地铁站点。使用 Get All Metros API 请求查找所有 Equinix Fabric 可用的地铁站点，并确定目的地位置。
-
确定云服务提供商的服务配置文件。使用 检索服务配置文件 API 请求搜索特定服务配置文件，或使用 获取服务配置文件 API 请求列出所有可用的服务配置文件，并确定要连接的云服务提供商。
连接到服务提供商
要将您的网络边缘设备连接到服务提供商，请向 /fabric/v4/connections 端点发送 POST 请求。在请求正文中指定连接的配置详细信息。
| POST /fabric/v4/connections | |
|---|---|
| Method | POST |
| Endpoint | /fabric/v4/connections |
| Headers | Authorization, Content-Type |
| Path Parameters | Not applicable |
| Query Parameters | Not applicable |
| Body Parameters | type, name, order, bandwidth, aSide, zSide, notifications |
cURL 请求示例：
curl -X
POST 'https://api.equinix.com/fabric/v4/connections'
-H 'content-type: application/json'
-H 'authorization: Bearer <token>'
-d '{
"type": "EVPL_VC",
"name": "vd2other-sp-0412a",
"bandwidth": 1000,
"aSide": {
"accessPoint": {
"type": "VD",
"virtualDevice": {
"type": "EDGE",
"uuid": "XXXXXXXXXXXXXXXXXXXXXXXXX"
}
}
},
"zSide": {
"accessPoint": {
"type": "SP",
"profile": {
"type": "L2_PROFILE",
"uuid": "XXXXXXXXXXXXXXXXXXXXXXXXXXXX"
},
"location": {
"metroCode": "DC"
}
}
},
"project": {
"projectId": "16799d66-ef43-445c-ba29-d17522d8a137"
},
"order": {
"purchaseOrderNumber": "1-129105284100"
},
"notifications": [
{
"type": "ALL",
"emails": [
"x@gmail.com"
]
}
]
}'
示例回答：
{
"type": "EVPL_VC",
"href": "https://api.equinix.com/fabric/v4/connections/53c89f1a-0be7-44a1-9c03-28059632a72d",
"uuid": "XXXXXXXXXXXXXXXXXXXXXXXXXXXX",
"name": "vd2other-sp-0425a",
"operation": {
"providerStatus": "PROVISIONING",
"equinixStatus": "PROVISIONING"
},
"order": {
"purchaseOrderNumber": "1-129105284100",
"billingTier": "Up to 1G"
},
"notifications": [
{
"type": "ALL",
"emails": [
"x@gmail.com"
]
}
],
"changeLog": {
"createdBy": "fabricamcrh1",
"createdByFullName": "fabric amcrh1",
"createdByEmail": "x@gmail.com",
"createdDateTime": "2024-04-25T20:40:40.676Z",
"updatedBy": "fabricamcrh1",
"updatedByFullName": "fabric amcrh1",
"updatedByEmail": "x@gmail.com",
"updatedDateTime": "2024-04-25T20:40:40.677Z"
},
"bandwidth": 1000,
"redundancy": {
"group": "43009a55-87ee-4dff-8ae4-70ccb7c3d4e9",
"priority": "PRIMARY"
},
"aSide": {
"accessPoint": {
"interface": {
"uuid": "XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX",
"id": 5,
"type": "CLOUD"
},
"location": {
"metroCode": "DC"
},
"virtualDevice": {
"uuid": "XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX",
"type": "EDGE"
}
}
},
"zSide": {
"accessPoint": {
"location": {
"metroCode": "DC"
},
"profile": {
"href": "https://api.equinix.com/fabric/v4/serviceProfiles/60ef0382-cdaa-44e7-bd36-b803731816b8",
"type": "L2_PROFILE",
"name": "Other Service Provider",
"uuid": "XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX"
}
}
}
}
监控连接状态
使用 Get 指定连接 端点来监控连接状态。
equinixStatus parameter values | providerStatus attribute values | Description |
|---|---|---|
PROVISIONING | PROVISIONING | Connection request has not been sent to Oracle yet. |
PROVISIONED | PROVISIONING | Connection establishment in progress. |
PROVISIONED | PROVISIONED | Connection established. |
