Versa FlexVNF (Self-Configured)
|
CPU = 2 cores Memory = 8G Disk size = 80G |
CPU = 4 cores Memory = 8G Disk size = 80G |
CPU = 6 cores Memory = 16G Disk size = 80G |
CPU = 16 cores Memory = 32G Disk size = 80G |
|
|---|---|---|---|---|
| Software Package | FlexVNF-2 |
FlexVNF-2 FlexVNF-4 |
FlexVNF-2 FlexVNF-4 FlexVNF-8 |
FlexVNF-2 FlexVNF-4 FlexVNF-8 FlexVNF-16 |
| Minimum Interfaces Supported (# data interfaces available) |
10 | 10 | 10 | 10 |
| Maximum Interfaces Supported (# data interfaces available) |
16 | 16 | 16 | 16 |
| Routing Domains | Internet-Transport-VRMPLS-EXT-Transport-VREquinix-LAN-VR | Internet-Transport-VRMPLS-EXT-Transport-VREquinix-LAN-VR | Internet-Transport-VRMPLS-EXT-Transport-VREquinix-LAN-VR | Internet-Transport-VRMPLS-EXT-Transport-VREquinix-LAN-VR |
| License Types Supported |
BYOL |
BYOL |
BYOL |
BYOL |
| Boot Time Average | 5 minutes | 5 minutes | 5 minutes | 5 minutes |
| BGP Local AS Support |
N/A | N/A | N/A | N/A |
| Access Methods | SSH Versa Director |
SSH Versa Director |
SSH Versa Director |
SSH Versa Director |
| Image Version | 16.1R2S8 | 16.1R2S8 | 16.1R2S8 | 16.1R2S8 |
| Throughput | Throughput (IMIX): 1 Gbps;1500B IP-Base: 4 Gbps; 1350B IP-SEC: 1 Gbps | Throughput (IMIX): 2 Gbps;1500B IP-Base: 12 Gbps; 1350B IP-SEC: 1 Gbps | Throughput (IMIX): 3.8 Gbps;1500B IP-Base: 12 Gbps; 1350B IP-SEC: 1.8 Gbps | Throughput (IMIX): 3.8 Gbps;1500B IP-Base: 12 Gbps; 1350B IP-SEC: 1.8 Gbps |
|
Services Offered |
|
|||
