Retrieving Assets

Assets (V1) API allows a user with View Install Base permission to search for installed assets based on a given criteria, and to fetch specific asset details.

Prerequisites

Authenticate - Submit your user credentials, Client ID, and Client Secret for OAuth2 authentication. Refer to API Authentication for instructions on how to call the OAuth API to validate and authenticate your credentials.

Searching for Asset and Asset Data

To search for asset information, send a POST request to the /assets/search endpoint. Specify your search criteria in the body of the request. Optionally specify the search behavior in the query parameters.

Method	POST
URL or End Point	/v1/assets/search
Headers	Authorization, Content-Type
Query Parameters	sorts, source, q, exactMatch, offset, limit
Body	filter{ibxs,cages,productTypes,dateRange{fromDate,toDate}}

Sample cURL Request:

This request indicates that a search for patch panels in IBX location, DA1; in the cage, DA1:01:009800; and installed within the dates 2003/07/17 to 2019/07/17 was done. The search results were sorted by ascending serial number, filtered for patch panels that only had asset numbers including 101, selected to start from index 0, and limited to 100 results per page.

curl -X
POST "https://api.equinix.com/v1/assets/search?sorts=SERIAL_NUMBER&source=ASSET_NUMBER&q=101&exactMatch=false&offset=0&limit=100"
-H "content-type: application/json"
-H "authorization: Bearer <token>"
-d '{
    "filter": {
        "ibxs": [
            "DA1"
        ],
        "cages": [
            "DA1:01:009800"
        ],
        "productTypes": [
            "PATCH_PANEL"
        ],
        "dateRange": {
            "fromDate": "2003-07-17T03:31:20.455Z",
            "toDate": "2019-07-17T03:31:20.455Z"
        }
    }

Sample Response:

{
    "data": [
      {
        "assetNumber": "10139297",
        "serialNumber": "PP:0210:73281",
        "orderNumber": 1-126273059,
        "productName": "PATCH_PANEL",
        "ibx": "DA1",
        "cage": "DA1:01:009800",
        "productDescription": "Patch Panel",
        "accountNumber": "987",
        "relatedAccountNumber": null,
        "accountName": "JOHN-DOE-CORP",
        "installationDate": "2009-05-14T00:00:00Z",
        "customerReferenceNumber": DAY-98278,
        "billingAgreementNumber": CAB-93678,
        "status": "ACTIVE",
        "additionalDetails": {
            "cabinetNumber": "DA1:01:009800:0210",
            "customerOrCarrierCircuitID": null,
            "finalzSideSystemName": null,
            "productBundle": null,
            "patchPanelNumber": "PP:0210:73281"
      }
    },
    {
        "assetNumber": "10147789",
        "serialNumber": "VP:0101:74679",
        "orderNumber": null,
        "productName": "PATCH_PANEL",
        "ibx": "DA1",
        "cage": "DA1:R1:V000170-1-294",
        "productDescription": "Patch Panel",
        "accountNumber": "987",
        "relatedAccountNumber": null,
        "accountName": "JOHN-DOE-CORP",
        "installationDate": "2009-07-09T00:00:00Z",
        "customerReferenceNumber": null,
        "billingAgreementNumber": null,
        "status": "ACTIVE",
        "additionalDetails": {
            "cabinetNumber": "DA1:R1:V000170-1-294:V1801",
            "customerOrCarrierCircuitID": null,
            "finalzSideSystemName": null,
            "productBundle": null,
            "patchPanelNumber": "VP:0101:74679"
        }
      }
    ],
    "page": {
        "limit": 100,
        "offset": 0,
        "total": 2,
        "sorts": [
        "SERIAL_NUMBER"
       ]
    },
    "_links": {
        "next": {
           "href": "/assets/search?q=101&exactMatch=false&offset=0&limit=100&source=ASSET_NUMBER&sorts=SERIAL_NUMBER"
        },
        "previous": {
           "href": "/assets/search?q=101&exactMatch=false&offset=0&limit=100&source=ASSET_NUMBER&sorts=SERIAL_NUMBER"
        },
        "self": {
           "href": "/assets/search?q=101&exactMatch=false&offset=0&limit=100&source=ASSET_NUMBER&sorts=SERIAL_NUMBER"
        }
    }
}

For a full list of response parameters, see the API Reference.

Get Assets

To get all details for a specific asset, send a GET request to the /assets/{assetId} endpoint. Specify the asset by ID in the path of the request.

curl -X
GET "https://api.equinix.com/v1/assets/{asset_id}"
-H "content-type: application/json"
-H "authorization: Bearer <token>"

Sample Response:

{
    "assetNumber": "9980813",
    "serialNumber": "1011585-M",
    "orderNumber": "1-198255055853",
    "productName": "CROSS_CONNECT",
    "ibx": "DC4",
    "cage": "DC4:01:043325",
    "productDescription": "Network Cable Connection",
    "accountNumber": "888",
    "accountName": "JOHN-DOE-CORPORATION",
    "installationDate": "2008-08-28T00:00:00Z",
    "customerReferenceNumber": "",
    "status": "Active",
    "productDetails": [
        {
            "key": "ACCOUNT_NAME",
            "value": "JOHN-DOE-CORPORATION",
            "tag": "HEADER"
        },
        {
            "key": "CUSTOMER",
            "value": "JOHN-DOE-CORPORATION",
            "tag": "A_SIDE_INFORMATION"
        },
        {
            "key": "ASSET_NUMBER",
            "value": "9980813",
            "tag": "OTHER_DETAILS"
        },
        {
            "key": "IFC_PANEL",
            "value": "No",
            "tag": "Z_SIDE_INFORMATION"
        }
    ]
}

For a full list of response parameters, see the API Reference.
